Truma MonoControl CS User Manual

14 EN
Technical data
(determined in accordance with EN 16129:2013 or Truma test conditions)
Gas type
Liquefied gas (propane / butane)
Admission pressure
0.3 – 16bar
Output pressure
30 mbar
Regulator capacity
1.5 kg/h
Regulator inlet
Male thread M20 x 1,5 (G.13)
Regulator outlet
Olive screw connection 8 mm or 10 mm (H.9)
Recommended tightening torque
3–5Nm for union nut M20x1.5 (G.13);
14–19Nm for olive screw connection 8mm;
16–21Nm for olive screw connection 10mm
Horizontal triggering value
4.0
g ± 1.0 g
Operating temperature
-20 °C to +50 °C
Product ID number: CE-0085CT0438
Subject to technical changes.

Truma MonoControl CS Specifications

General

Category	Controller
Safety feature	Crash sensor
Operating pressure	30 mbar
Regulator capacity	1.5 kg/h
Type	Gas pressure regulator
Gas type	Propane/butane
Inlet pressure	0.3 to 16 bar
Installation	Vertical
Power Supply	Not applicable
Display	No
