Page #54 background image
48
SETx
±nnn.nn
Sets the end-trigger level for stopping data acquisition.
SET Denotes set end-trigger.
x Denotes trigger source: F = flow.
± Denotes positive or negative trigger: + = positive, - =
negative.
nnn.nn Sets trigger level (‘001.00’ could denote 1.00 Std L/min,
leading zeros must be included).
The set trigger level stays in effect until cleared using the CET
command. The trigger level is also cleared when the flowmeter is
turned off or the DEFAULT command is initiated. The SAVE
command does not save this parameter.
After the command is processed, an acknowledge sequence of “OK”
<CR> <LF> is sent. If the command generated an error instead of
“OK” <CR> <LF> being sent, an error code of “ERRn” <CR> <LF> will
be sent. See Appendix A
for a list of possible error codes.
Example 1) SETF-002.00 Sets an end-trigger level of a flow of 2.00
Std L/min with negative slope.
