TSI Instruments 4000 Series User Manual

49
CBT
Clears the begin-trigger level that was set with SBTx±nnn.nn. Begin-
trigger function is disabled. The flowmeter will return an acknowledge
sequence of “OK” <CR> <LF> as a response.
Example 1) CBT
CET
Clears the end-trigger level that was set with SETx±nnn.nn. End-
trigger function is disabled. The flowmeter will return an acknowledge
sequence of “OK” <CR> <LF> as a response.
Example 1) CET
SSRnnnn
Sets the sample rate at which the data is returned.
SSR Denotes set sample rate.
nnnn Denotes number of milliseconds per sample, range 1 to 1000.
(‘0005’ denotes 5 milliseconds per sample, leading zeros
must be included).

TSI Instruments 4000 Series Specifications

General

Measurement Parameters	Velocity, Temperature
Data Storage	10, 000 data points
Accuracy	±0.015 m/s or ±1% of reading
Particle Size Range	Not applicable
Display	LCD
Operating Humidity	0 to 95% RH (non-condensing)
