REPLACING THE CAP SENSOR BATTERY (CR2032)
17
TST-Doc-507FT-RV WSD-C Manual-(D)
(1). Remove the sensor from the tire valve stem.
(2). Use the specified wrench to open the sensor cap counterclockwise.
(3). Slide the battery out of the cage sideways. Note that the (+) side is up. Replace
with a new CR2032 battery that is 3+ volts.
(4). At this time check the"O"ring at the base of the threads. Be sure it is in place.
If it is worn or broken, replace it.
Specified
wrench
Loosen the hex nut
Waterproof
rubber seal
To Next Page
