TTI 1705 - Page 5

(AC + DC) Voltage Accuracy
Total measurement error will not exceed the sum of the separate ac and dc accuracy
specifications plus 1 display count.
Resistance
Range Accuracy Resolution
100Ω
0.1% ± 3 dig.
10mΩ
1000Ω
0.08% ± 2 dig.
100mΩ
10kΩ
0.09% ± 2 dig.
1Ω
100kΩ
0.09% ± 2 dig.
10Ω
1000kΩ
0.12% ± 2 dig.
100Ω
10MΩ
0.5% ± 2 dig.
1kΩ
20MΩ
0.5% ± 2 dig.
10kΩ
Maximum Input: 300V DC or AC rms, any range.
Maximum Open Circuit Voltage: 4V
DC Current
Range Accuracy Resolution
1mA 0.1% ± 3 dig. 100nA
100mA 0.1% ± 3 dig. 10uA
10A 0.3% ± 3 dig. to 1A 1mA
10A 1.0% ±3 dig. to 5A 1mA
10A 3% ± 10 dig to 10A 1mA
Maximum Input: mA ranges - 500mA DC or AC rms, 250V, fuse protected.
10A range - 10A DC or AC rms, 250V, fuse protected.
Typical Voltage Burden: mA ranges - <250mV
10A range - <500mV
AC Current (True RMS)
Range Accuracy (45Hz - 10kHz) Resolution
1mA 0.35% ± 20dig. 100nA
100mA 0.35% ± 20 dig. 10uA
10A 0.5% ± 20 dig. to 1A 1mA
10A 1.2% ± 20 dig to 5A 1mA
10A 3% ± 20 dig. to 10A 1mA
Accuracy specifications apply for readings between 1,000 and 12,000 counts. Additional error at
crest factory = 3 typically 0.2%.
Maximum Input: mA ranges - 500mA DC or AC rms, 250V, fuse protected.
10A range - 10A DC or AC rms, 250V, fuse protected.
Typical Voltage Burden: mA ranges - <250mV
10A range - <500mV
4
