Frequency
Range Accuracy Resolution
100Hz 0.01Hz
1000Hz 0.01% ± 1 dig. 0.1Hz
10kHz 1Hz
100kHz 10Hz
Range: 10Hz to 100kHz
Input sensitivity: Better than 30m Vrms (100mV range); better than 10% of range
for all other Vac and Iac ranges.
Capacitance
Range Accuracy Resolution
10nF
10pF
100nF 100pF
1uF 2% ± 5 dig. 1nF
10uF 10nF
100uF 5% ± 5 dig. 100nF
Continuity and Diode Test
Continuity:
1000Ω range selected; audible tone sounds for impedance <10Ω.
Diode Test: Test current approximately 0.5mA; displays voltages up to 1.2V.
Maximum Open Circuit
Voltage:
4V
Maximum Input: 300V DC or AC rms, any range.
DISPLAY
Display Type: High contrast LCD. Main display 4½ digits 17mm high, secondary
display 5 digits 10mm high.
Scale Length: 4¼ digits (12000 counts) in most modes.
Annunciators: LCD annunciators for all ranges, functions and program modes.
Reading Rate: Varies with function, maximum 4/sec.
Overrange: Display flashes 12000 if input too great for range.
Overflow: Displays -Or- if calculated result overflows display.
COMPUTING FUNCTIONS
Null (Relative) Stores current reading and subtracts it from future readings.
Ω Null:
Additional non-volatile function for nulling test lead resistance.
Hold: Reading is frozen
T-Hold (Touch & Hold): Reading is frozen when stable.
dB:
Displays measurement in dBm relative to 600Ω or other user-entered
impedance.
5
