9. Band Selection
UE
(EU/UK)
I
I2
D
D2
EU
EC
E
F
PL
UK
DisplaySettings Band
Europe 40 Ch FM 4W
Spain 40 Ch AM/FM 4W
France 40 Ch FM 4W, 40 Ch AM 1W
UK 40 Ch FM 4W (British Frequencies)
Italy 40 Ch AM / FM 4W
Italy 34 Ch AM / FM 4W
Germany 80 Ch FM 4W, 12 Ch AM 1W
Germany 40 Ch FM 4W, 12 Ch AM 1W
Europe 40 Ch FM 4W, 40 Ch AM 1W
UK 40 Ch FM 4W (British Frequencies)
+ CEPT 40 Ch FM 4W (EC)
Poland 40 Ch AM / FM 4W
(Polish Frequencies : 5KHz)
Pressing AM/FM button and Scan
button at the same time, turn on the
transceiver. Using the channel selector,
select the band that you are
going to select. The LCD display offers you the band information.
The band chart for each area is as follows.
Press AM/FM button while the band information is blinking or wait
for 5 seconds to complete the selection and go to the transmit and
receive mode. This transceiver has "EC" band setting when it is
shipped out from the factory.
12
TCB-771
ENGLISH
