6
Remove the cleaning system from the carton
and inspect for damage or missing compo-
nents. Keep box for storage or shipping unit
if service is required.
Place unit on a hard level surface and
visually verify that the oil level is at the dot in
center of gauge. The unit is shipped slightly
overfilled. Tip case to see air bubble before
operation.
Be sure the power switch is in the “OFF”
position.
Set unit on a hard level surface. Do not oper-
ate unit in tall grass or on other soft surface
that would restrict air flow to and from the
bottom of the case.
Attach the high pressure hose quick-discon-
nect to the discharge nipple on the top of the
case by pulling back the collar and pressing
over the nipple. Push down until it snaps into
position.
ASSEMBLY AND START-UP
CAUTION
Lack of proper lubrication will result in
severe damage to pump. Visually check oil
before each use.
NOTE
When attaching accessories to the inlet
connection or chemical injector, some
movement may be noticeable. Each con-
nection is o-ring sealed and the movement
is normal.
AIR FLOW
