TuffStuff HTX-2000 - Step 13: Low Row Cable Routing

www.tu stu tness.comHTX-2000 Dual Stack-Funtional Trainer



Step 13 Low Row Cable Routing
25
şŗ
řŝ
řŚ
řŞ
śş
řş
NOTE:
1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
2. ONCE PULLEYS ARE INPLACE, MAKE NECESARY
ADJUSMENT TO THE CABLE ON THE ADJUSTABLE PULLEY BRACKET #18.
3. MAKE SURE TO TIGHTEN SCREW ITEM NO. 91
MAKE SURE CABLE RUNS
UNDERNEATH SCREW #74
AS SHOWN ABOVE.
100%
Fully Tighten
Fully Tighten
Wrench tighten all hardware in this step.
