TuffStuff SXT-550 - Page 27

SXT-550 Deluxe Hybrid Trainer www.tustutness.com
27
Step 8 Assembly List
Item # Description Qty.
*2 ADJUSTABLE PULLEY BRACKET (4 1/2) 1
*11 FLOATING TRIPLE PULLEY BRACKET 1
15 LAT CABLE (3/16” CABLE) 1
52 7/8 RD X 1 5/8 LINK 3/16 CABLE 1
76 CABLE STOPPER SHELL 1 1/2 X 1 3/4 1
108 NYLON SHORT HANDLE 1
109 OVAL HEAD PHILLIPS MACHINE SCREW Z/P #10-32 X 1 1/8 1
129 SNAP LINK Z/P 8MM X 80MM 1
Note:
1. Some parts not shown/cut out for clarity.
