TuffStuff SXT-550 - Page 35

SXT-550 Deluxe Hybrid Trainer www.tustutness.com
35
Step 11 Assembly List
Item # Description Qty.
*28 OFFSET DOUBLE PULLEY BRACKET 1
30 PRESS BAR CABLE (3/16” CABLE) 1
42 SELECTOR PIN 1
81 FINISHED HEX NUT Z/P 1/2-13 1
85 FLAT WASHER SAE Z/P 3/8” 2
96 BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 5/8 1
97 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 (RND CUT) 1
107 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 1
124 RUBBER BUMPER 1
142 SPLIT LOCK WASHER Z/P 1/2” 1
151 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS ASSY 1
Note:
1. Some parts not shown/cut out for clarity.
