P. 14
Terminal in the wall (horizontal:
To prevent disruption
Distance: terminal to A, B of C
At walls in multi-storey buildings
Not permitted when A, B of C is above
the terminal
At walls – in general. (*)
Above terminal: >2m
Below terminal: >0,75m
Left and right of terminal: >0,75 m
At <1m of roof edge.
>2m
Below balconies, galleries etc
>2m to underside of the protruding
balcony or gallery
Under balconies, walkways and the
terminal extends to the front
>2m
In the garden or at the terrace
>2m to outdoor (**)
Relative to a facing wall
>2m (if the distance to the opposite wall
is less, applies to both facades the
conditions given in "wall-general")
Check with your local gas company for the requirements relating to outlets in two
opposite walls and outlet (s) in wall (s) that form an angle.
(*) This minimal distances do not apply if there is an obstruction, which protrudes at least 0.5 m
from the wall and has a length which is greater than the distance between the outlets A, B, or C
(**) This distance is not required if the outlet is at least 1m higher than the referred area from
outside is.
Outlets at a distance of less than 2m above and less than 0.5 m measured horizontally from the hard
surface of a public area placed must have an effective protector. This shielding may not affect the
proper functioning of the device.
3.4.4 Horizontal terminal type C
11
Flue sizes:
B-Fire 35, 50, 60, 80 : Ø100/150
B-Fire 95, 100, 100H : Ø130/200
B-Fire 150, B-Fire 120 : Ø130/200
