Tunturi C20 - Page 80

80
C-20
No. Description QTY
1 Console 1
2 Screw 3
3 Handlebar post 1
4 Hand pulse sensor wire 1
5 Console wire 1
6 End cap 2
7 Foam grip 2
8 Hand pulse sensor 2
9 Front post cover 2
10 Console bracket 1
11 Console bracket seat 1
12 Flat washer Ø6xØ13x1t 2
13 Nylon nut M6 1
14 Console locking knob 1
15 Fixed washer 1
16 Screw M5x14L 2
17 Screw M4x16L 2
18 Screw M5x20L 2
19 Handlebar axle bushing 2
20 Handlebar cap 2
21 Bushing Ø6.0*Ø9.8*50L 2
22 Screw M6x60L 1
23 Handlebar fixed axle 1
24 Main frame 1
25 Hex. Screw M8xP1.25x12Lx5t 3
26 Driving pulley 1
27 Bushing Ø20.5xØ25x7.5mm 1
28 Axle 1
29 Locking screw 2
30 Nylon nut M20 1
31 Flat washer Ø20.3xØ30x1t 1
32 Sensor wire 1
33 Tension cable 1
34 Screw M4xP1.5*16L 2
35 Sensor holder 1
36 Flat washer Ø5xØ10x1t 2
37 Bearing 6004RS 2
38 Driving belt 1
39 Side cover ( L) 1
40 Side cover ( R) 1
41 Top cover 1
42 Handlebar post cover 1
43 Ring for handlebar post 1
44 Cover of bottom tube 1
45 Screw M4x16 3
46 Flat washer Ø10xØ18x1t 2
47 Screw M5x16 5
48 Shaft of chain cover 2
49 Pin 2
50 Hex. screw M10xP1.5x50L 2
51 Hex. screw M5*P0.8*16L 2
52 Nylon nut M10 2
53 Pedal arm front cover, left 2
54 Pedal arm front cover, right 2
55 Cap for handlebar R/L 2
56 Cap for Pedal arm R/L 2
57 Fixed tube of semi-bracket 2
58 Bottle holder 1
59 Tension control 1
60 Disc crank 2
61 Crank cap (outer) 2
62 Crank cap (Inner) 2
63 Screw M5x6L 4
64 Flywheel assy set (65~72) 1
65 Flywheel 1
66 Nut 3/8“ 3
67 Axle for flywheel 1
68 Flat washer Ø10xØ14x1t 1
69 Bearing 6000RS 1
70 Bearing 6300RS 1
71 Plastic sleeve 1
72 Pattern nut 2
73 Magnetic brake set 1
74 Hex. screw M6xP1.0*16L 2
75 Flat washer Ø6xØ13x1t 2
76 Spring washer Ø6 2
77 Belt tightener 1
78 Wheel for belt tightener 1
79 Curved washer
Ø10.5xØ15x0.3t
2
80 Nylon nut M8 1
81 Flat washer Ø8.5xØ25x2t 1
82 Flat washer Ø6xØ13x1t 2
83 Hex. screw M6xP1.0x80L 1
84 Hex. screw M6xP1.0x12L 1
85 Hex. screw M6xP1.0x18L 1
86 Spring 1
87 Flat washer Ø10xØ14x1t 1
88 Front foot 1
