40
40 533 7045 Plastic insert 2
41 203 7017 Handle bar, left
(incl 36, 40, 42) 1
42 213 7008 Handle grip, pair 2
43 533 7047 Handlebar end cap 2
*44 M8 DIN 440 Washer M8 OD 28mm 2
45 233 7012 Computer 1
46 M5x10 DIN 7985 Screw 4
47 203 7019 Fix handlebar
(incl. 48,49,83,84) 1
48 403 7016 Pulse grip unit (incl. 49) 2
*50 653 7023 Spring knob 2
*51 M6x45 ISO 7380 Screw 4
52 503 7010 Sensor bracket 1
53 M3x8 DIN 7985 Screw 2
54 523 409 85 Bearing 4
55 17 DIN 417 Clip C17 <ID 15.7mm> 3
56 343 7020 Axle for pulley 1
57 263 7007 Pulley (si. 80) 1
58 503 7011 Safe bracket 1
59 M6x18 DIN 933 Screw 4
60 M6 DIN 985 Nylock nut 5
61 513 7001 Bracket (incl. 54, 55) 1
62 643 7001 Carge spring 1
63 523 7014 Spacer sleeve 3
64 M6x12 DIN 933 Screw 3
65 373 7006 Magnetic bow 1
66 M8x52 DIN 931 Screw 1
67 M8 DIN 985 Nylock nut 1
68 M6x65 DIN 931 Screw 1
69 M6 DIN 985 Nylock nut 1
70 653 7027 Nylon washer M6 1
71 643 7002 Spring 1
72 303 7002 Flywheel
(incl. 73, 74, 75, 77, 78) 1
73 523 504 85 Bearing 2
74 343 7021 Flywheel axle 1
75 12 DIN 471 Clip C12 <ID 11.1mm> 2
76 443 7003 Belt 1
77 M10 DIN 125 Washer 2
78 653 7026 “3/8”” Wh nut” 2
79 433 7003 Turning peda, right 1
80 403 7017 Magnet 1
81 433 7004 Turning pedal, left 1
82 M8x16 DIN 933 Screw 2
83 533 7046 Fix handlebar end cap 2
84 213 7009 Fix handlebar grip 1
- 423 7052 Lable set 1
- 553 7004 Assembly kit (incl *) 1
- 583 7008 Owner’s manual 1
