PARTS LIST
1 Base frame 1
2 Upright tube (incl. part 52) 1
3 Upper moving handle bar (L) (incl. part 64, 83) 1
4 Upper moving handle bar (R) (incl. part 64, 83) 1
5 Lower moving handle bar (L) (incl. part 52) 1
6 Lower moving handle bar (R) (incl. part 52) 1
7 Pedal tube (L) (incl. part 53-55) 1
8 Pedal tube (R) (incl. part 53-55) 1
9 Outer pedal post (L) (incl. part 55) 1
10 Outer pedal post (R) (incl. part 55) 1
11 Front foot (incl.19,32,37,48,61,84,103) 1
12 Middle foot (incl. part 61) 1
13 Rear foot (incl. part 58,61) 1
14 Cross frame 2
15 Rail for roller 2
16 Axle for pulley 1
17 Axle for moving handle bars 1
18 Pedal shaft 2
19 Transport wheel bushing 4
20 Fixed handle bar bracket 1
21 Pedal fixing bracket 2
22 Fixed handlebar (incl. part 59,82,90,91,100) 1
23 M5*20mm DIN 7981C Self tapping screw 16
24 M6*14mm ISO 7380 Allen head screw 4
25 M6*53mm DIN 912 Allen head screw 1
26 M5*12mm DIN 7985A Screw 8
27 M6*10mm DIN 7985A Screw (*1 pc) 1
28 M8*15mm ISO 7380 Allen head screw (*8 pcs) 8
29 M8*20mm ISO 7380 Allen head screw (*6 pcs) 10
30 M8*42mm ISO 7380 Allen head screw (*2 pcs) 2
31 M8*58mm ISO 7380 Allen head screw (*4 pcs) 4
32 M8*63mm ISO 7380 Allen head screw 2
33 M6*12mm DIN 7981 C Screw 1
34 M6*18mm DIN 933 Hex head bolt 4
35 M5*1,5mm DIN 125A Washer 8
36 M8*25mm ISO 7380 Allen head screw (*2 pcs) 2
37 M8*1,2mm DIN 125A Washer (*22 pcs) 30
38 M8*2*28mm Washer (*2pcs) 2
39 M8*2*38mm Washer (*4pcs) 4
40 Axle for roller 2
41 Extension wire 1
42 M8 DIN 127 B Spring washer (*34 pcs) 38
43 M8*56mm ISO 7380 Alen head screw (*4 pcs) 4
44 M8 DIN 137 A Curve washer (*10 pcs) 10
45 3/8” turning plate axle nut 2
46 M6 DIN 985 Nyloc nut 4
47 M6 DIN 985 Nyloc nut 1
48 M8 DIN 985 Nyloc nut (*4 pcs) 6
49 17*1mm DIN 471 Retaining ring 3
50 6203 ZZ Bearing 2
51 6001 ZZ Bearing 4
52 Moving handle bar bushing 2
53 Inner pedal post bushing_1 2
54 Inner pedal post bushing_2 2
55 Pedal post bushing 8
56 Oval end cap 1
57 Square cap for 30 x 70mm tube 1
58 Round end cap for rail tube 2
59 Fixed handlebar end cap 2
60 Roller (incl. part 51) 2
61 Height adjustment screw 6
62 Turning plate 2
63 Belt 1
64 Moving handlebar end cap 2
65 Head tube sleeve 1
66 Main cover (L) 1
67 Main cover (R) 1
68 Screw cover 2
69 Front foot cover 1
70 Middle foot cover 1
71 Roller cover 2
72 Sensor wire 1
73 Upper UI cable 1
74 Lower UI cable 1
75 DC wire 1
76 Pedal 2
77 Pulley (incl. part 94) 1
78 Turning plate cap 2
79 UI mounting clamp 1
80 Base for user interface 1
81 Head tube adaptor 1
82 Fixed handlebar foam 2
83 Moving handlebar foam 2
84 Transport wheel 2
85 M5*15mm DIN 7981C Screw (*2 pcs) 2
86 Plastic spacer for control board 2
87 M8*15mm ISO 7380 Allen head screw (*8 pcs) 8
88 EMS system (incl. part 63) 1
89 Sensor bracket 1
90 Hand pulse sensor set 2
91 Hand pulse wire 2
92 M6*1,2mm DIN 126 Washer 4
93 User interface UI 1
94 Magnet 9
95 Control board 1
96 Adaptor 26V/2.3A 1
100 M3*12mm DIN 7981C Screw 2
101 M5*12mm DIN 7985A Screw 4
102 M5*30mm DIN 7981C Screw (*2 pcs) 2
103 M5*20mm DIN 965A Self tapping screw 2
104 M6*1,2mm DIN 126 Washer 1
107 M6 DIN 127 B Spring washer 4
108 M6*15mm DIN 7985A Screw (*2 pcs) 2
109 Plastic spacer 2
110 M5 DIN 127 B Spring washer 8
111 M6*2T DIN 127 B Spring washer (*2 pcs) 2
112 M4*15mm DIN 7981C Screw 4
- Hardware kit 1
- Owner’s manual 1
- Warranty booklet 1
- Label set 1
