Cleaning and Maintenance
18
Side Racks Re-Fitting
Right Rack
a. Align the bottom of the rack with the 2 brackets in the
bottom RH side of the oven.
b. Tilt the rack upwards and hook the top rear of the rack on
to the locating peg in the top rear of the oven.
c. Fit and tighten the rack securing screw to secure the front
of the RH rack.
Left Rack
a. Locate the top rear of the rack onto the locating peg at the
top rear LH side of the oven.
b. Locate the top front of the rack over the locating peg at
the top front LH side of the oven.
RH Lower Mounting Brackets
R/Hand Rear
Locating Peg
L/Hand Rear
Locating Peg
Tighten Clockwise
Oven Lamp
a. Remove the LH side rack as shown previously.
b. Wash the glass lens with a soft sponge using warm water
and a detergent solution. Rinse with clean, warm water.
c. Dry the glass lens thoroughly with a dry cloth.
d. Refit LH side rack as shown previously.
