Replacement Parts List
22
When ordering replacement parts, please quote the part number and the description as listed below. If the part required
is not listed below, request the part by description and quote model number and serial number which is shown on the
Technical Data Plate.
Important:
Only genuine authorized replacement parts should be used for the servicing and repair of this oven. The instructions
supplied with the parts should be followed when replacing components.
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer.
Item Description
236256 Digital Control Board Kit.
234450 Encoder.
234447 Control Knob.
234429 Transformer 208 / 240V x 12V AC SEC, 20VA.
234460 Cooling Fan 230V.
237447K Temperature Probe Kit PT1000
234821 Overtemp Thermostat 355°C / 670°F.
231738 Contactor - Heating.
231742 Contactor - Motor Speed.
236107K Oven Element, 6300W, 230 - 240V.
236108K Oven Element, 6300W, 208 - 220V.
236264 Element Gasket. (included in Oven Element Kit).
237335 Fan Motor, L7-EB50, 2 / 4 Pole, 2 Speed.
235610 Motor Shaft Seal.
234138 Fan - Dia 8½” / 220mm, 50Hz.
234252 Motor Capacitor 10uF.
234875 Motor Capacitor 3uF.
021352 Oven Glass Lens.
231814 Lamp Bulb G9 25W, Halogen, 230V.
021354 Oven Lamp Gasket.
234803 Fuse 10A, 250V.
020851 Water Solenoid.
021057 Spray Nozzle Assembly.
232666 Oven Door Seal - E32D.
234757 Door Inner Glass Assembly
234581 Door Handle E32D.
234580 Door Roller Catch.
235277 Door Roller Catch Strike Pin.
024802 Door Microswitch E32
235278 Strike Lock Nut
234626 Door Hinge Top
234627 Door Hinge Bottom
232379 Foot Adjustable (73 - 80mm).
232380 O-Ring
234658 Side Rack LH, 5 Tray.
236546 Side Rack RH, 5 Tray.
233649 Oven Rack.
233552 Rack Securing Screw.
234625 Fan - Dia 8” / 200mm, 60Hz.
Item Description
236060 Core Temperature Probe Kit.
235845 Core Temperature Probe.
235847 Dust Cap - Core Temperature Socket.
236271 Core Temperature Probe Holder.
Optional Extras
