57 Manchester Series MAN210-FG/MS121/MAN210-HC Rigging Manual
Chapter 10: Enclosure quantities and combinations for MAN210-FG y
grid suspension at 10:1, 7:1, and 5:1 design factors
Maximum allowed MV210-HC and MS121 enclosure quantities and combinations for suspension using MAN210-FG Fly Bar at 10:1, 7:1 and 5:1 design factors.
MAN210-FG Working Load Limit W.L.L
Suspension W.L.L with a 10:1 Safety Factor
3 Point System : MV210-HC 496 kg / 1091.3 lbs
4 Point System : MS121 821 kg / 1810 lbs
Measured Weights
Item Measured Weight
MV210-HC 35.5 kg
MS121 87.5 kg
MAN210-FG with Tip Bar 32.8 kg
MV210-HC Arrays
Safety Factor Qty MV210-HC Weights kg Total Weight with Fly Grid kg Description
10 to 1 1 35.5
10 to 1 2 71
10 to 1 3 106.5
10 to 1 4 142
10 to 1 5 177.5
10 to 1 6 213
10 to 1 7 248.5
10 to 1 8 284
10 to 1 9 319.5
10 to 1 10 355
10 to 1 11 390.5
10 to 1 12 426
10 to 1 13 461.5 494.3 Maximum quantity at 10:1
7 to 1 14 497
7 to 1 15 532.5
7 to 1 16 568
7 to 1 17 603.5
7 to 1 18 639 671.8 Maximum quantity at 7:1
5 to 1 19 674.5
5 to 1 20 710
5 to 1 21 745.5
5 to 1 22 781
5 to 1 23 816.5
5 to 1 24 852
5 to 1 25 887.5
5 to 1 26 923 955.8 Maximum quantity at 5:1
