Turtle Beach Ear Force Foxtrot - Computer (PC;Mac) Setup; PC;Mac Connection Diagram; Product Specifications

13
14
Computer (PC/Mac) Setup / Configuration Ordinateur (PC/Mac) /
Computer (PC/Mac)-Setup
green / vert / grün
USB
Specifications / Caractéristiques / Spezifikationen
HEADSET
• 40mm diameter speakers with neodymium magnets
• Speaker Frequency Response: 20Hz - 20kHz, >120dB SPL @ 1kHz
• Condenser Microphone Frequency Response: 50Hz - 15kHz
• Cable length: 16 ft. (4.87m)
• Weight: 6.4 oz (233g)
IN-LINE AMPLIFIER
• Headphone Amplier: Stereo DC-coupled, 35mW/ch, THD <1%, Frequency Response: DC - 30kHz
• Bass Boost continuously adjustable from 0dB to +12dB @ 50Hz
• Mic mute switch
• Stereo expander switch
• Maximum analog input level with volume control on maximum setting: 2Vpp (700mV rms)
• 3.5mm plug for line output
• USB connector for power, mic connection and stereo audio
• 2.5mm mic output jack
• USB connector for power (5VDC @ <60mA max)
• Dimensions: Height .5in (1.27cm), Width 2in (5.08cm), Depth .75in (1.905cm)
