11
Storage Temperature
-40°F~185°F (-40°C~85°C)
Cable Length
90 inches (2300 mm)
Size
3.5”x3.8”x0.9” (88 x 96 x 23 mm)
Weight
6 Oz (170 g)
3.3 Receiver Specifications
ITEM
SPECIFICATION
Operating Voltage
12~24V DC
Operating Current
120 mA
Operating Frequency
433 MHz
Operating Temperature
-4°F~185°F (-20°C~85°C)
Storage Temperature
-40°F~185°F (-40°C~85°C)
Monitored Pressure Range
0~203 ±1.5 psi (0~1400 ±10 kPa)
Monitored Temperature Range
-40
o
F~257
o
F ±5.4
o
F (-40
o
C~125
o
C ±3
o
C)
Size
4.5”x2.1”x1” (116.5 x 53 x 25 mm)
Weight
3.4 Oz (95 g)
Note: When using kPa as the unit of air pressure, the monitor will display “Hi” if the air pressure is over
999kPa. The actual air pressure values will be displayed numerically when the unit of measure selected is
in psi or Bar.
