14
For Other Custom Vehicle Configurations, please see note below:
Note: For initial installation, the sensor orientation mark should be installed in the following order:
1. Sensors on the LEFT side are ODD numbered
2. Sensors on the RIGHT side are EVEN numbered
3. Each vehicle side will have sensors increase in odd or even consecutive order from front to back
4. For vehicles with dually axles, the outside tires should have the lower numbered marking and
the inside tires should have the higher numbered marking.
*Wheel orientation marks used per vehicle selection: CAR 1 ~ 1-10, CAR 2 ~ 11-20, CAR 3 ~ 21-30
<IMPORTANT 2>
The sensors’ ID# and wheel orientation mark included in the kit are listed in Section “12.3 Sensor ID#s
List for Each Vehicle Memory Selection of each user manual. BEFORE installing additional sensors
not included in the kit, it is highly recommended that the sensor ID#s be recorded in Section 12.3 next to
the corresponding wheel orientation mark for easy identification when pairing.
The Interchangeable Valve Stem (IVS) Service Kit
The Tuson TPMS tire sensors use a metal interchangeable valve stem (IVS) that fits through 0.453" and
0.625" diameter wheel valve holes. (Note: If neither grommet size fits the wheel valve hole, a TPMS band
and cradle kit can be purchased separately without replacing the existing valve stem.)
Please circle the grommet size that was used for your tire application for easy identification and
replacement: 0.453” or 0.625”.
