30
During Driving Mode, the receiver will monitor all the installed sensors and the tow vehicle battery
voltage. The receiver will alert the user of the following sensor and tow vehicle battery issues:
• TPMS System Alarm: indicates that the sensor signal was lost since the receiver has not
received a sensor signal from a specific wheel for at least 10 minutes. (Note: This does not
activate when the vehicle is stopped.)
• Sensor Low Battery Power: indicates that the sensor’s battery power status is low.
• Low Battery Power on the tow Vehicle (12V): indicates tow vehicle battery voltage≦11.5V.
System
Alarm Image
Indicators
• alarm symbol will appear on the left side of the display in red
• Tire/wheel location will turn red and blink
• Sensor pressure/temperature value become “---” and will turn red
