Parts List
Parts List for Model 150 to 400 Series – Slinger Splash Lube
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR 2
3 HOUSING 1
4 ENDPLATE 2
6 COVER D.E. 1
7 COVER F.E. 1
8 GEAR ASSEMBLY 1
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER 2
14 BEARING RETAINER 2
16 SHIM, TIMING, .010" 2
16 SHIM, TIMING, .003" 6
16 SHIM, TIMING, .005" 2
17 SPACER 2
21 SLINGER, OIL 1
22 PIN, DOWEL, 3/8 X 7/8 6
23 KEY,1/4 SQUARE X 1 3/4 1
24 KEY, GEAR TIMING 2
25 WASHER, ROTOR SHAFT 4
26 SCREW, CAP, HEX HEAD, 1/4 24
29
SCREW, CAP, SOCKET HEAD,
3/8
4
31
PLUG MAG-3/4- 16UNF HEX
HEAD W/O-RING
2
38 PORT 2
40 SCREW, CAP, HEX HEAD, 5/16 24
42 NAMEPLATE 1
42 TAG, WARNING 1
45 SHAFT, DRIVE 1
50 BEARING, BALL, 2 ROW 1
57 SPACER 2
62 SCREW, CAP, HEX HEAD, 1/4 8
66
SCREW, CAP, SOCKET HEAD,
5/16
2
67 SPACER 2
74 SPACER 1
75 O-RING, VITON 1
76 SEAL,MECH 1
77 SPACER 1
79 SLINGER, SEAL STATOR 4
82 WASHER DUST 1
83 LOCKNUT 1
ITEM
NO.
PART DESCRIPTION QTY
85 PLUG, PIPE, 1/4 HEX, STEEL 4
94 COIL,COOLING- COPPER 2
95 O-RING, FKM 4
96 O-RING, VITON A 4
97 BUSH,COOLING COIL,BRASS 4
98
PLUG, PIPE, 1/8 SQUARE,
STEEL
2
118 SHIM, .010 THICK 2
123 BEARING SPACER 2
166
CONNECTOR, HOSE, 1/4 X 1/8
MPT - BRASS
2
174 PLUG, PIPE, 1/2 HEX, STEEL 1
180
ELBOW, STREET - 1/8" NPT -
BRASS
2
181 HOSE, ID, 1/4 21
195 LIFTING LUG 2
234 TAG, OIL LEVEL 4
238 SLINGER, SEAL ROTOR 4
241
SCREW, HH CAP 10-32 X .63
STEEL NYLOK
24
242 FRAME, SIGHT GAUGE 4
243
WINDOW, SIGHT GLASS
GAUGE
4
244 GASKET, WINDOW 4
245 GASKET, FRAME 4
346
PLUG, STRAIGHT THREAD, 3/4,
STEEL
2
500
THERMOSWITCH **35 FT-LB
TORQUE**
1
506
CAPLUG, COOLING COIL, 1/8"
NPT, RED
2
OTE: N
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
