Tuthill 150 - Models 850 to 2700 - Dimensions

Manual 2003 Rev D p/n 2003
53
Assembly Drawings
Models 850 to 2700 – Dimensions
1.4956
37.988
2.756
70.00
.500
12.70
266.70
10.500
319.46
12.577
CONFIDENTIAL AND IS THE PROPERTY OF THE
TUTHILL CORPORATION. THE INFORMATION
SCALE WEIGHT
REVDWG NO.
SHEET
SIZE
TITLE
APPROVALS
DATE
CHECKED
DRAWN
THIRD ANGLE PROJECTION
C
1 OF 11:4
5507MF2Lxxx2EA -
LB
BLOWER OUTLINE
PA
BB
03/02/2020
WHATSOEVER.
SHALL NOT BE USED OR DISCLOSED BY THE
03/02/2020
US CUSTOMARY IN
SYSTEMS
INTERPRET PER ASME Y14.5-2009
VACUUM & BLOWER
RECIPIENT FOR ANY OTHER PURPOSE
UNLESS OTHERWISE SPECIFIED
NOTICE OF CONFIDENTIAL INFORMATION
INFORMATION CONTAINED HEREIN IS
.XX 0.25
BREAK ALL SHARP EDGES, CORNERS,
DEBURR AND CLEAN
DN 150 PN 10 FLANGE
ON 241.30[9.500] B.C.
11.000
279.40
8X 22.23 0.875 THRU
EQUALLY SPACED
22.5°
KEY
10mm WIDE
2.750
69.86
17.152
435.66
368.30
14.500
184.15
7.250
218.81
8.615
G
B
A
C
E
F
F
D
850 TO 2700 DIMENSIONS
MODEL A B C D E F G
850
29.51 in.
(750 mm)
17.83 in.
(453 mm)
11.69 in.
(297 mm)
10.50 in.
(267 mm)
6"FLG
150 DN
10.00 in.
(254 mm)
20.50 in.
(521 mm)
1200
33.01 in.
(838 mm)
19.58 in.
(497 mm)
13.69 in.
(348 mm)
14.00 in.
(368 mm)
6"FLG
150 DN
10.00 in.
(254 mm)
20.50 in.
(521 mm)
1600
36.01 in.
(915 mm)
21.08 in.
(535 mm)
14.85 in.
(377 mm)
17.00 in.
(445 mm)
6"FLG
150 DN
10.00 in.
(254 mm)
20.50 in.
(521 mm)
2000
40.01 in.
(1019 mm)
23.08 in.
(586 mm)
16.85 in.
(428 mm)
21.50 in.
(546 mm)
8"FLG
200 DN
10.00 in.
(254 mm)
20.50 in.
(521 mm)
2700
46.01 in.
(1169 mm)
26.08 in.
(662 mm)
19.85 in.
(504 mm)
27.50 in.
(699 mm)
10"FLG
250 DN
10.00 in.
(254 mm)
20.50 in.
(521 mm)
