Tuthill 150 - Models 540 to 720 - C-Flange - Dimensions

Manual 2003 Rev D p/n 2003
51
Assembly Drawings
Models 540 to 720 – C-ange – Dimensions
REV ECN DESCRIPTION DATE DR CK
A- SEE SHEET 1 01/23/2020 TAAL MS
.90
6.63 2.00
13.26
1.08 5.25
10.50
SCALE WEIGHT
REVDWG NO.
SHEET
SIZE
TITLE
APPROVALS
DATE
CHECKED
DRAWN
THIRD ANGLE PROJECTION
D
2 OF 31:3
EX4012-F2L4CVC00-2 A
LB
BLOWER ASSEMBLY
TAAL
MS
01/23/2020
05/15/2020
US CUSTOMARY IN
VACUUM & BLOWER
SYSTEMS
INTERPRET PER A SME Y14.5-2009
UNLESS OTHERWISE SPECIFIED
NOTICE OF CONFIDENTIAL INFORMATION
INFORMATION CONTAINED HEREIN IS
CONFIDENTIAL AND IS THE PROPERTY OF THE
TUTHILL CORPORATION. THE INFORMATION
SHALL NOT BE USED OR DISCLOSED BY THE
RECIPIEN T FOR ANY O THER PURPOSE
WHATSOEVER.
.XX 0.25
BREAK ALL SHARP EDGES, CORNERS,
DEBURR AND CLEAN
2.17
7.88
8.00
.50
B
A
C
E
F
F
D
G
.53
540 TO 720 DIMENSIONS
MODEL A B C D E F G
540
29.24 in.
(743 mm)
13.63 in.
(346 mm)
11.25 in.
(286 mm)
11.50 in.
(292 mm)
4"FLG
100 DN
7.50 in.
(191 mm)
15.50 in.
(394 mm)
720
32.24 in.
(819 mm)
15.13 in.
(384 mm)
12.75 in.
(324 mm)
14.50 in.
(368 mm)
4"FLG
100 DN
7.50 in.
(191 mm)
15.50 in.
(394 mm)
