Tuthill 150 - Models 150 to 400 - C-Flange - Dimensions

Manual 2003 Rev D p/n 2003
47
Assembly Drawings
Models 150 to 400 – C-ange – Dimensions
5.50
8.20
1.94
.8656±.0005
3.30
REV ECN DESCRIPTION DATE DR CK
-- See Sheet 1 - --
SC A LE W EI G HT
REVDWG NO .
SHEET
SI ZE
TI TLE
A PPRO VA LS
D A TE
C HEC KED
D RA W N
THIRD ANGLE PROJECTION
D
2 O F 2
1:2
400MF2L2D-6600B
A
194.6 LB
BLO W ER A SSEM BLY
TAAL
JK
02/ 04/ 2020
05/ 11/ 2020
US C USTO MA RY IN
VACUUM & BLOWER
SYSTEMS
INTERPRET PER ASME Y14.5-2009
UN LESS O THERW ISE SPEC IFIED
NOTICE OF CONFIDENTIAL INFORMA TION
INFO RM ATION C ON TA INED HEREIN IS
C O N FID EN TI A L A N D I S THE PRO P ERTY O F THE
TUTH IL L C O RP O RA TIO N . THE IN FO RM A TI O N
SHA L L N OT B E USED O R D ISC LO SED BY TH E
REC IPIEN T FOR A N Y OTH ER P URPO SE
W HA TSO EVER.
.XX 0.25
BREAK ALL SHARP EDGES, CORNERS,
DEBURR AND CLEAN
1.63 5.49
11.90
3.75
7.50
G
B
A
C
E
F
F
D
.41
150 TO 400 DIMENSIONS
MODEL A B C D E F G
150
20.93 in.
(532 mm)
14.31 in.
(363 mm)
6.62 in.
(168 mm)
6.62 in.
(168 mm)
2" FLG
50 DN
5.82 in.
(148 mm)
12.13 in.
(308 mm)
240
22.93 in.
(582 mm)
15.31 in.
(389 mm)
7.62 in.
(193 mm)
7.62 in.
(193 mm)
3" FLG
80 DN
7.44 in.
(189 mm)
12.94 in.
(329 mm)
400
26.93 in.
(684 mm)
17.31 in.
(440 mm)
9.62 in.
(244 mm)
11.62 in.
(295 mm)
4"FLG
100 DN
7.44 in.
(189 mm)
12.94 in.
(329 mm)
