Tuthill 150 - Models 150 to 400 - Dimensions

Manual 2003 Rev D p/n 2003
45
Assembly Drawings
Models 150 to 400 – Dimensions
SCALE WEIGHT
REVDWG NO.
SHEET
SIZE
TITLE
APPROVALS
DATE
CHECKED
DRAWN
THIRD ANGLE PROJECTION
D
2 OF 31:2
EX3206MF2L2DVS00-2 A
LB
BOOSTER ASSEMBLY
PKA
MS
04/20/2020
04/20/2020
US CUSTOMARY IN
VACUUM & BLOWER
SYSTEMS
INTERPRET PER A SME Y14.5-2009
UNLESS OTHERWISE SPECIFIED
NOTICE OF CONFIDENTIAL INFORMATION
INFORMATION CONTAINED HEREIN IS
CONFIDENTIAL AND IS THE PROPERTY OF THE
TUTHILL CORPORATION. THE INFORMATION
SHALL N OT BE USED OR DI SCLOSED BY THE
RECIPIEN T FOR ANY O THER PURPOSE
WHATSOEVER.
.XX 0.25
BREAK ALL SHARP EDGES, CORNERS,
DEBURR AND CLEAN
3.81
5.50
1.1019±.0005
2.74
9.23
1.63 5.49
10.71
3.75
7.50
REV ECN DESCRIPTION DATE DR CK
-- - - --
G
B
A
C
E
F
F
D
.41
150 TO 400 DIMENSIONS
MODEL A B C D E F G
150
18.66 in.
(474 mm)
12.04 in.
(306 mm)
6.62 in.
(168 mm)
5.62 in.
(143 mm)
2" FLG
50 DN
5.82 in.
(148 mm)
12.13 in.
(308 mm)
240
20.66 in.
(525 mm)
13.04 in.
(331 mm)
7.62 in.
(193 mm)
7.62 in.
(193 mm)
3" FLG
80 DN
7.44 in.
(189 mm)
12.94 in.
(329 mm)
400
24.66 in.
(626 mm)
15.04 in.
(382 mm)
9.62 in.
(244 mm)
11.62 in.
(295 mm)
4"FLG
100 DN
7.44 in.
(189 mm)
12.94 in.
(329 mm)
