Tuthill 3003 - Torque Chart

Manual 2017 Rev C p/n 2017
41
TORQUE CHART
11
PART DESCRIPTION TORQUE
CAP SCREW 10-32UNF
3 ft-lb
(4 N-m)
CAP SCREW 1/4"-20UNC GR5
6 ft-lb
(8 N-m)
CAP SCREW 5/16"-18UNC GR5
13 ft-lb
(17 N-m)
CAP SCREW 3/8"-16UNC GR5
23 ft-lb
(31 N-m)
CAP SCREW 1/2"-13UNC GR5
57 ft-lb
(77 N-m)
CAP SCREW 5/8"-14UNC GR5
113 ft-lb
(153 N-m)
CAP SCREW 3/4"-10UNC GR5
200 ft-lb
(271 N-m)
Data shown represents “wet” torque values in foot-pounds and (Newton-meters).
