Parts List
Parts List for Model CP Series – Splash Lubrication / Air Service
ITEM
NO.
PART DESCRIPTION QTY
1 Housing 1
2 Mounting Foot 2
3 Drive End Plate 1
4 Gear End Plate 1
5 Gear End Cover 1
6 Drive Rotor 1
7 Driven Rotor 1
8 Gear Set 1
9 Dowel Pin 4
10 Drive End Cover 1
11 Bearing 1
12 Bearing 1
13 Bearing Ball 2
15 Screw, Socket Head 14
16 Screw, Socket Head 16
17 Screw, Socket Head 6
18 Pipe Plug 8
18 Magnetic Plug 4
21 Oil Sight Glass 4
22 Bearing Retainer 2
23 Lip Seal 1
24 Lip Seal 4
25 Screw, Hex Head 8
26 Washer 3
27 Breather 2
28 Spacer 2
29 Cap Screw 3
30 Shim 6
30 Shim 2
30 Shim 2
31 Key Gear 2
42* Nameplate 1
44 Roll Pin 2
45* Lifting Lug 2
ITEM
NO.
PART DESCRIPTION QTY
46* Slinger Oil-2, Machine-1 2
48* Roll Pin 2
* Not shown
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
