Tuthill 3003 - Parts List for Model CP Series - Grease Lubrication; Air Service

Manual 2017 Rev C p/n 2017
47
Parts List
PARTS LIST
Parts List for Model CP Series – Grease Lubrication / Air Service
ITEM
NO.
PART DESCRIPTION QTY
1 Housing 1
2 Mounting Foot 2
3 Drive End Plate 1
4 Gear End Plate 1
5 Gear Cover 1
6 Drive Rotor 1
7 Driven Rotor 1
8 Gear Set 1
9 Dowel Pin 4
10 Cover Grease 1
11 Bearing 1
12* Bearing 1
13 Bearing 2
15 Screw, Socket Head 14
16 Screw, Socket Head 8
17 Screw, Socket Head 6
18 Pipe Plug 3
18 Magnetic Plug 2
19 Relief Fitting 2
20 Grease Fitting 2
22 Bearing Retainer 2
23 Lip Seal 1
24 Lip Seal 4
25 Screw, Hex Head 8
26 Washer 2
27 Breather 1
28 Spacer 2
29 Cap Screw 2
30 Shim 6
30 Shim 2
30 Shim 2
31 Key Gear 2
42* Nameplate 1
ITEM
NO.
PART DESCRIPTION QTY
45* Lifting Lug 2
* Not shown
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
