● This product provides a REMOTE
CONTROL mode. The user may connect
RJ-45 jack to the REMOTE terminal on the
rear of the unit and designate a function
for each pin.
● The default settings are as follows:
PIN 1 : ANALOG CHANNEL
PIN 2 : MODE CHANNEL
PIN 3 : PBP CHANNEL
PIN 4 : TALLY R
PIN 5 : TALLY G
PIN 6 : TALLY Y
PIN 7 is POWER ON/OFF use only, PIN 8 is GND
● The pin positions are as follows :
● Selectable functions are as follows :
LVM-327W
SDI A
[5] GPI
5. Menu Operations
PAGE I >> PAGE II
GPI 1
GPI 2
GPI 3
GPI 4
GPI 5
GPI 6
GPI 7
GPI 8
ANALOG CHNNEL
MODE CHANNEL
PBP CHANNEL
TALLY R
TALLY G
TALLY Y
POWER ON
GND
REM
O
TE (
R
J
-45
)
1:
P
in1
2
:
P
in2
3:
P
i
n
3
4:
P
in4
5: P
i
n5
6:
P
i
n
6
7:
P
in7
8
:
G
ND
1
8
Menu
Classi-
cation
Settable Values
PIN
1~6
NONE,
ANALOG CHANNEL,
SDI A CHANNEL, SDI B CHANNEL,
PBP CHANNEL,
TALLY R, TALLY G, TALLY Y,
UNDER SCAN, 1:1 SCAN,
ASPECT, H/V DELAY,
BLUE ONLY, MONO,
16:9 MARKER,
4:3 MARKER, 4:3 ON AIR MARKER,
15:9 MARKER,
14:9 MARKER,
13:9 MARKER,
1.85:1 MARKER,
2.35:1 MARKER,
1.85:1&4:3 MARKER,
CENTER MARKER,
SAFETY AREA 80%,
SAFETY AREA 85%,
SAFETY AREA 88%,
SAFETY AREA 90%,
SAFETY AREA 93%,
SAFETY AREA 100%, 708,
608(LINE 21), 608(ANC),
DYNAMIC-UMD,
COMPOSITE 1,
COMPOSITE 2,
COMPOSITE 3,
S-VIDEO,
COMPONENT,
RGB,
DVI-ANALOG, DVI-DIGITAL,
HDMI,
OP47, OP42, OP47/42(AUTO),
708-KOR,
TELETEXT PAGE 801,
TELETEXT PAGE 888,
TELETEXT PAGE 889
PIN 7
POWER ON/OFF CONTROL
PIN 8
GND
