8. Product Specifications
* The specication above may be changed without notice.
LVM-327W
LCD
Size 31.5”
Resolution 1920 X 1080
Pixel Pitch 0.363(H) X 0.363(W) mm
Color Depth 10bit, 1,073,741,824 Colors
Viewing Angle H: 178degrees / V: 178degrees
Luminance of white
500 cd/ m
2
Contrast Ratio 1300 : 1
Display Area 698.40(H) X 392.85(V) mm
Input Connector
1 X DVI-I DVI-I(RGB) IN
3 X BNC Analog Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC Analog Output
2 X BNC
SDI A/B Channel (Loop Through Out)
1 X BNC EXT SYNC OUT(Active Through Out)
Input Signal
Analog Composite/ S-Video / Component Video / RGB
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA/IBM Modes
HDMI 480i / 480p / 720p / 576i / 576p / 1080i / 1080p & VESA / IBM Modes
Analog Input Spec
Composite 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB
1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i (60/59.94/50)
SMPTE-372M
Dual HD-SDI YPbPr (4:2:2) 1080p(50/59.94/60)
Dual HD-SDI YPbPr RGB (4:4:4)
1080p(50/59.94/60)
1080p/psf(30/29.97/25/24/23.98)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
2K Format 2048 x 1080(23.98p/psf, 24p/psf)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Internal Speaker(Stereo)
Power AC100~240V(50~60Hz)
Power Consumption (Approx.) 145 Watts(Max.)
Operating Temperature
0℃ to 35℃ (32
℉
to 95
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 769.4 x 485.1 x 102.1 (30.29 x 19.1 x 4.01)
Main Body Dimensions with stand (mm/inch) 769.4 x 539.3 x 255 (30.29 x 21.23 x 10)
Box Dimensions (mm/inch) 920 X 675 X 350 (36.22 X 26.57 X 13.78)
Weight 22.25Kg / 49.05 lbs
Basic Accessories AC Power Cord, Stand, Manual
Optional Accessories Carrying Case
