16
LVM-171W / 241W / 401W / 461W / 571W
[3] MARKER menu
· MARKER
This selects the marker type when the MARKER is displayed on the screen. MARKER
may only be activated by pressing the MARKER button on the front of the monitor.
Available MARKER types are as follows:
· CENTER MARKER
This item displays the CENTER MARKER on the screen. This function operates only
after activating the MARKER function by pressing the MARKER button on the front of
the monitor.
· SAFETY AREA
This item controls the size of the SAFETY AREA between 80%, 88%, 90%, 93%, 100%,
EBU ACTION 16:9, EBU GRAPHIC 16:9, EBU ACTION 14:9, EBU GRAPHIC 14:9,
EBU ACTION 4:3 and EBU GRAPHIC 4:3.
· FIT MARKER
This item activates the Fit Marker Function. With Fit Marker On the Safety Area is
displayed relative to the Marker in use. With Fit Marker Off the Safety Area is displayed
relative to the incoming source.
MODE MARKER CLASS
HD
SD 16:9
16:9, 4:3, 4:3 ON AIR, 15:9, 14:9, 13:9, 1.85:1, 2.35:1, 1.85:1
& 4:3, USER
SD 4:3
16:9
