TVLogic LVM-232W User Manual

12 Multi Format LCD Monitor
3. Controls & Functions
LVM-182W/232W : FRONT
● [STATUS INDICATOR] Lamp
- Used to display the current input mode.
- Input Mode
CVBS : COMPOSITE
DVI-A : DVI ANALOG
DVI-D : DVI DIGITAL
HDMI : HDMI
SDI : SDI-A / B
● [ANALOG] Button/Lamp
- Used to select desired Analog input.
- Press the button to activate the analog
input menu-selection, then use UP
and DOWN button to select desired input.
*
Please refer to “7. Button Functions [1]
ANALOG Button” for more information.
● [DIGITAL] Button/Lamp
- Used to select desired Digital input. (HDMI,
DVI Digital)
- Press the Digital Button to activate the
Digital input menu-selection, then use the
Knob to select desired input.
*
Please refer to “7. Button Functions [2]
DIGITAL” for more information.
● [SDI-A] Button/Lamp
- Used to select SDI-A input.
● [SDI-B] Button/Lamp
- Used to select SDI-B input.
● [F1 ~ F5] Button/Lamp
- Performs the function that the user set as
hot-keys.
- The selectable the hot-key menu comes up
when you hold the keys. You can select the
hot-key functions from it.
● [SCAN] Button/Lamp
- Used to change the scan mode. Press the
button to activate through the scan modes:
OVER SCAN > USER ASPECT > ZERO SCAN >
UNDER SCAN > 1:1 SCAN > FIT WIDTH
* Please refer to “8. Other Functions [1]SCAN”
for more information.
● [ASPECT] Button/Lamp
- Used to change the display ratio between
4:3 and 16:9.
- Activates in order of : 16:9 -> 4:3 -> 2.35:1 ->
1.85:1 -> 15:9 -> 16:10 -> Auto
*
Display ratio is xed as 16:9 if the display
ratio of input signal is 16:9.
● [MARKER] Button/Lamp
- Used to activate/deactivate the Marker.
- The Marker is normally displayed when you
select Aspect ratio you want in OSD Menu.
● [H/V DELAY] Button/Lamp
- Used to check horizontal sync. and vertical
sync. simultaneously.
● [BLUE ONLY/MONO] Button/Lamp
- Activates in the order of [O]-[Blue Only]-
[Mono]-[Focus Assist]-[O]
- Press the button to remove red and green
from the input signal and display the screen
only under a blue signal. Press the button
again to activate mono mode.
● [INFO.] Button/Lamp
- Shows current monitor’s status.
