TVLogic LVM-232W User Manual

Multi Format LCD Monitor 51
* The specication above may be changed without notice.
10. Product Specifications
LVM-246W
LCD
Size 24.1”
Resolution 1920 X 1200 (16:10)
Pixel Pitch 0.270(H) X 0.270(V) mm
Color Depth 16.7M (True 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white
300 cd/ m
2
(Center)
Contrast Ratio 1000 : 1
Display Area 518.4(H) X 324.0(V) mm
Input Connector
1 X DVI-I DVI-IN
3 X BNC
Analog Video Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC
Analog Output
1 X BNC SDI Channel (Active Through Out)
Input Signal
Analog Composite / S-Video / Component / RGB
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA/IBM Modes
HDMI 480i / 480p / 720p / 1080i VESA/IBM Modes
Analog Input Spec
Composite 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Speaker (Mixed Mono)
Power DC 24V / AC 100~240V (50~60Hz)
Power Consumption (Approx.) 112 Watts(Max.)
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 552 x 389 x 95.9 (21.73 x 15.31 x 3.78)
Main Body Dimensions with stand (mm/inch) 584 x 417 x 150 (23.01 x 16.41 x 5.90)
Box Dimensions (mm/inch) 673 X 535 X 280 (26.50 X 21.06 X 11.02)
Weight 10.35Kg / 22.82 lbs
Basic Accessories AC Power Cord / Stand / Manual
Optional Accessories Rack Mountable Kit, Carrying Case, ND Filter
