Multi Format LCD Monitor 45
<Color Bar + Pluge Pattern>
<Gray Pattern>
● Displays internally generated test
patterns.
- The pattern consists of ColorBar and Pluge+
Grayscale Patterns. Full screen colors
of various gray levels(0~100%) are also
embedded.
[9] INTERNAL PATTERN
● Displays current status and function
setting of the monitor.
● It displays when you press [Info.] in front
of the monitor.
1. [Format] : Current input signal
2. [Color Temp.] : Current color temperature.
3. [F1][F2][F3][F4][F5] : Current hot-key setting
status.
4. [Scan] : Current scan setting status.
5. [Aspect] : Current aspect ratio setting
status.
6. [Waveform]
7. [Audio level meter]
8. [User cong.]
9. [Time code]
10. [Focus Assist]
11. [Closed caption]
12. [UMD Display]
13. [Key LED]
14. [Remote control]
15. [Fan enable]
[10] INFO. (LVM-182W/232W)
8. Other Functions
