Multi Format LCD Monitor
19
3G FORMAT
- Selects input format for SDI 3G A/B support (NORMAL MODE, A 444 10BIT_YCbCr, A 444, 10BIT_RGB,
A 444 12BIT_YCbCr, A 444 12BIT_RGB, A 422 12BIT_YCbCr, B 444 10/12BIT_YCbCr, B 444 10/12BIT_
RGB, B 422 12BIT_YCbCr, B 422 10BIT_YCbCr, 60P).
- Automatically detects when Payload signal appears in normal mode.
OUTPUT MODE SELECT
- Selects luminance range in SDI MODE between FULL (255) and NORMAL (235).
RGB INPUT MODE
- DVI-DIGITAL/HDMI MODE Selects input luminance range.
- Available values are RGB255, RGB235Ex and RGB235.
*
RGB 255 : Input : 0 ~ 255, Output : 0 ~ 255
*
RGB 235Ex : Input : 16 ~ 235, Output : 0 ~ 255
*
RGB 235 : Input : 16 ~ 235, Output : 16 ~ 235
- Only available in DVI DIGITAL and HDMI Modes.
DVI INPUT FORMAT SELECT
- Selects input color formats between RGB and YPbPr.
- Only available in DVI DIGITAL Mode.
Menu Contents
To Next Page
