TVLogic LVM-243W-3G User Manual

Multi Format LCD Monitor
46
Multi Format LCD Monitor
46
Product Specications
LVM-173W-3G
LCD
Size 16.84”
Resolution 1366 X 768 (16:9)
Pixel Pitch 0.273(H) X 0.273(W) mm
Color Depth 16.7M (True 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white 350 cd/ m
2
(Center)
Contrast Ratio 900 : 1
Display Area 372.9(H) X 209.6(V) mm
Input
1 X DVI-I DVI-I(RGB) IN
3 X BNC Analog Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC Analog Output
2 X BNC SDI A/B Channel (Active Through Out)
Input Signal
Analog Composite / S-Video / Component / RGB
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA / IBM Modes
HDMI 480i / 480p / 720p / 1080i & VESA / IBM Modes
Analog Input Spec
Composite 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G with Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) 1080i(60/59.94/50)
SMPTE-372M
(Dual Link Option)
Dual HD-SDI YPbPr (4:2:2) 1080p (50 / 59.94 / 60)
Dual HD-SDI YPbPr/RGB (4:4:4)
1080p (50 / 59.94 / 60)
1080p/psf (30/29.97/25/24/23.98)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
2K Format 2048 X 1080 (23.98p/psf, 24p/psf)
Audio In Analog Stereo (Phone Jack), Embedded Audio
Audio Out Analog Stereo (Phone Jack), Internal speaker (stereo)
Power DC 12V/24V/AC100~240V (1.8A/50~60Hz)
Power Consumption (Approx.) 65 Watts(Max)
Operating Temperature
0୅Gto 40୅G(32එGto 104එP
Storage Temperature
-20୅Gto 60୅G(-4එGto 140එP
Main Body Dimensions (mm/inch) 427 X 310 X 90.5 (16.8 X 12.2 X 3.5)
Main Body Dimensions (with stand) 474 X 327 X 150 (18.6 X 12.8 X 5.9)
Box Dimensions (mm/inch) 555X 450 X 280 (21.85 X 17.72 X 11.02)
Weight 7Kg / 15.4 lbs
Accessory AC Power cord
Option Carrying Case, V-Mount, Hood, 19” Rack Mountable Kit, ND Filter
*
Above specications may be changed without notice.
