TVLogic R-5T User Manual

LCD Rack Mountable Monitor 28
[7] SYSTEM / GPI / UMD
5. Menu Operations
Bit 1
(Tally2)
Bit 1
(Tally1)
Operation
0 0
CHANNEL1
0 1
CHANNEL1
1 0
CHANNEL1
1 1
CHANNEL1
Bit 1
(Tally4)
Bit 1
(Tally3)
Operation
0 0
CHANNEL1
0 1
CHANNEL1
1 0
CHANNEL1
1 1
CHANNEL1
Activates as follows when the UMD DISPLAY is set to D-UMD(D-8C) and the D-UMD TALLY TYPE
and the TALLY1 ~ TALLY4 COLOR is set to as below.
D -UMD TALLY T YPE
TALLY1 COLOR
TALLY2 COLOR
TALLY3 COLOR
TALLY4 COLOR
USER COLOR
RED
GREEN
RED
YELLOW
CHANNEL1 CHANNEL1
● Tally Type - Default
- S-8C(Single 8 Character) & S-16C(Single 16 Character)
● D-UMD TALLY TPYE - USER COLOR
- Used to set the color of the TALLY1 ~ TALLY4.
- D-8C(Dual 8 Character)
