10. PARTS CHANGE DETAILS
1. Damper weight handle bar : N9150770
2. Longer and heavier than the RTR 160 damper to reduce handle
bar vibration. This modified damper will also be shortly
introduced in RTR 160cc.
3. The modified part can be interchanged as a set (LH & RH side)
on existing RTR 160 vehicles.
4. Incase any necessity arise to change both LH and RH, replace
with the modified damper (180 cc).
5. However both old and modified damper will be serviced for
replacing LH or RH side individually on old vehicles.
1. Lower bracket complete : N9100460
2. No change in part no.
3. Height of the bracket for fork holding increased for better life.
4. Can be identified by pip provided the lower bracket complete.
5. The modified part can be interchangeable with existing Apache /
RTR 160 vehicles.
6. Only modified part will be serviced in spares.
1. Leg assembly front fork LH : N91009608R
Leg assembly front fork RH : N91009708R
Tube outer LH : N91008208R
Tube outer RH : N91008708R
2. Fork outer tube finish changed to golden yellow colour.
3. Though this tube outer RH & LH can be functionally fitted
on RTR 160, it is not recommended due to change in colour &
aesthetic reasons.
4. Front fork assembly will be serviced in spares under
part No. N91010808R
1. Swingarm complete : N9092230 (with bush)
2. Swingarm length increased to suit modified wheel base and
better performance.
3. Can be identified by modified shockabsorber mounting bracket.
4. Not interchangeable with existing RTR 160 vehicles.
-17-
LEG ASSEMBLY FRONT FORK
LOWER BRACKET COMPLETE
DAMPER WEIGHT HANDLE BAR
SWINGARM COMPLETE
Modifed bracket
Pip
