10. PARTS CHANGE DETAILS
1. Rear sprocket : N9112570
2. Rear sprocket teeth increased from 44 T to 46 T for better
ride feel performance
3. Not interchangeable with existing RTR 160 vehicles.
4. Can be identified by the 46T mark engraved on the surface of the
sprocket.
5. Drum sprocket assembly will be serviced under
part No. N9112580
1. Chain assembly : N9112830
2. Chain assembly length increased from 124 L to 130 L.
to match longer wheel base and modified sprocket teeth.
3. Servicing procedure for O ring chain is same as exlained
Apache RTR refresh 160 cc (Refer SER.INF / APACHE
RTR - REVISION 1). After every water servicing Cleaning &
lubrication the 'O' - Ring chain if necessary.
4. Not interchangeable with existing RTR 160 vehicles.
1. Chain cover : N9091700
2. Chain cover is modified with releif cut to suit modified
wheel assembly.
3. The modified part can be used with existing RTR 160cc vehicles
and hence no change in part number. However the old part
available at dealership under same part number must be
used only for RTR 160 cc. Do not use the old Part in
RTR 180 cc.
4. Only new part will be serviced in spares.
1. Shock Absorber LH : N9092250
Shock Absorber RH : N9092260
2. Shock absorber body colour changed to golden yellow for better
aesthetics & the Spring rating is modified for better performance.
3. Not interchangeable with existing RTR 160 vehicles.
-18-
SHOCK ABSORBER
CHAIN COVER
CHAIN ASSEMBLY
REAR SPROCKET
46-T
Cut provided
