Overall length
2085 mm
Overall width
730 mm
Overall Height
1105 mm
Seat height
790 mm
Ground clearance
165 mm
Wheel base
1326 mm
Kerb weight 137 kg with toolkit and 90% of fuel
Pay load
130 Kg
Gross vehicle weight
266 Kg
Type 4 stroke, air cooled, single cylinder OHC
Bore
62.5 mm
Stroke
57.8 mm
Piston displacement
177.4 cc
No.of valves
2
Carburettor type
UCAL Mikuni BS-29
Air filter Double polyurethane foam filter element
Oil filter Wire mesh and micronic paper filter
Lubrication system Forced wet sump
Compression ratio 9.5 : 1
Maximum power in kW
12.52 (17 bhp) @ 8500 rpm
Maximum torque
15.5 Nm @ 6500 rpm
Maximum speed 124 km / hr
Engine idling rpm 1400 ± 100 rpm
Starting system Kick starter / Electric starter
Clutch system Wet - multiplate type
Gear shift pattern 1 down and 4 up
Primary transmission Helical gears
Secondary transmission Chain and sprockets
First gear 2.917
Second gear 1.857
Third gear 1.333
Fourth gear 1.050
Fifth gear 0.880
Primary reduction 3.095
Secondary reduction 3.286
Frame type Double cradle Synchro STIFF
Front suspension Telescopic oil damped
ENGINE
TRANSMISSION
GEAR RATIO
CHASSIS
-2-
1. GENERAL INFORMATION
TECHINICAL SPECIFICATIONS
DIMENSIONS AND WEIGHT
