ELECTRICAL
Body earthing : Negative terminal
Head lamp : 12V, 35/35W x 1
Position lamp : LED
Tail / brake lamp : 12V, 5/21W x 1
Turn signal lamp : 12V, 10W x 4
Instrument panel : LCD / LED indicators
Horn : 12V, DC x 1
Main fuse : 12V, 10A x 1
Head lamp fuse : 12V, 10A x 1
Vehicle location device
remote battery : 3V, CR2016 x 3 (Lithium)*
CAPACITIES
Fuel tank capacity : 12.0 liters (including reserve)**
Reserve : 2.0 liters
Engine cum transmission : TVS TRU4 PREMIUM oil
oil grade (SAE 10W30 API-SL, JASO MA2 )
Engine cum transmission : 1000 ml
oil and capacity
Front fork oil grade : IOC / Castrol teleshockab oil
Front fork oil capacity : 155 ± 2 ml per leg ( for GIL make)
: 140 ± 2.5 ml per leg (for TOP make)
Brake fluid : TVS Girling DOT 3 / DOT 4*
** The fuel tank is not a measuring instrument and the
capacity of fuel tank may slightly vary from the indicated
capacity.
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Caution
Using the bulb other than the specified rating can
result in overloading of the electrical system or
premature failure of the bulb.
Note
Specifications are subjected to change without
notice.
-64-
* Applicable only for Disc version
