VERA10 Operating Manual
2.3.2. Vertical selector switch
The "High shelf attenuation" vertical selector switch lowers the frequency range above
2 kHz independent of the VERA10P operating mode.
In the "0dB normal operation" mode, the frequency response is not attenuated above
2kHz.
In the "-6dB short throw" mode, the frequency response above 2 kHz is attenuated by
6dB.
In the "-3dB mid throw" mode, the frequency response above 2 kHz is attenuated by
3dB.
Figure 2.3.2 - High frequency range attenuation
