4
VERA10 Operating Manual
The VERA10 loudspeaker comes in four different variants. These are differentiated by
their horizontal coverage (80° or 120°) and are further subdivided into VERA10A (BI-
AMP model) and VERA10P (PASSIVE model).
2.2.1. Horn – horizontal coverage 80°/120°
The VERA10 loudspeaker can be equipped with either an 80° × 10° horn or a 120° × 10°
horn. The degrees refer to the horizontal and vertical radiation angles. The VERA10
horn variant can be identified by the legend printed on the horn (see figure 2.2).
The horn can be exchanged for the other type at any time. See section 4.2 "Exchanging
the horn".
Figure 2.2 - VERA10 horn variants
2.2.2. VERA10A/VERA10P models
The standard model of the VERA10 loudspeaker is the VERA10A, which can only be op-
erated in the "biamped" mode. It is supplied with a standard connection panel and re-
quires two amplifier channels for operation. The compression driver and cone driver are
separated by the DSP of the amplifier.
The VERA10P model can additionally be switched to the "passive" mode. This enables
operation with only one amplifier channel, for which the enclosure contains a passive
crossover. The built-in passive crossover features 2 selector switches described in
section 2.3.
2.2 Variants
80°
120°
80°
120°
