VERA10 Operating Manual
The passive version (VERA10P) features two selector switches on the rear
(figure 2.3.1) for switching between two different operating modes and for attenuating
the high frequency range (see figure 2.1, no. 16).
2.3.1. Horizontal selector switch
In the "PASSIVE" mode, the loudspeaker is operated on a passive audio crossover with
a single amplifier channel.
In the "BIAMP" mode, the internal passive crossover bypasses the signal path and the
individual routes of the loudspeaker must be driven separately by two DSP channels.
Figure 2.3.1 - VERA10P operating modes
2.3 Operating modes
PASSIVE MODE
0 dB
-6 dB
-3 dB
PASSIVE
BIAMPED MODE
0 dB
-6 dB
-3 dB
BIAMPED
NOTE
Never change the operating mode while the loudspeaker is connected. In addition to set-
ting the switch, the corresponding preset on the amplifier must be changed.
Operating with an incorrect preset may damage parts of the loudspeaker.
