Rebar Scanner A60+
20
includes data of grid pattern scan. Project whose No. is begun with
4XXX includes data of section plane scan. Press the ↑ and ↓keys to
select different projects in project No. region. Arrowhead indicates
current selected project. Data of current selected project is in right
data region.
No. Data
Known Dia.16 =>1002
1005
2003
3001
4001
4003
3002
27 28 27 27
28 27
Figure 3-17 Interface of viewing thickness
Look up data of this project by means of pressing ← and →keys.
→key is used to look up data of current project backwards through the
full screen turning.←key is used to look up data of current project
forwards through the full screen turning. Press the ESC key to return
the function selection interface.
When project No. begun with 1XXX is selected through ↑ and
↓keys, that is to say, interface of viewing the thickness as figure 3-17
shown, Dia. known is the set diameter during detection according to
design data. Following data are those of detecting covering layer
thickness in this project.
When project No. begun with 2XXX is selected through ↑and ↓,
