Rebar Scanner A60+
22
the second line. YΦ08 indicates preset diameter of horizontal rebar for
this project No., which corresponds to following data including data of
detecting covering layer thickness of horizontal rebar in the first line
and the distance that this rebar is relative to the zero point in the
second line.
When project No. begun with 4XXX is selected through ↑ and
↓keys, that is to say, interface of viewing data of section plane scan as
figure 3-20 shown. Detected rebar No., covering layer thickness and
the distance that rebar is relative to the zero point in this project are
showed in right data region. Serial number of detected rebar is showed
under the NO. Data of detecting covering layer thickness are showed
under the H/16 under the condition of known rebar diameter (16mm).
Horizontal distance that rebar is relative to the zero point is showed
under the Dx.
No. Data(mm)
No Xø16
Yø08 1002
1005
2003
=> 3001
4001
4003
3002
01
02
03
04
034
0086
026
0159
024
0288
030
0098
031
0277
Figure 3-19 interface of viewing grid scan
