For engraving ：
REFERENCE OF MATERIALS
Material
TTS 5.5Pro
Speed (mm/min)
TTS 5.5Pro
Power (%)
Times
Plywood
Acrylic
Leather
Electroplated coating
Powder coating
Anodic alumina
Stainless steel
MDF
Peddle
Plastic sheet
Cardboard
1500
1500
3000
300
1500
1500
1000
1500
1500
1500
1500
20
20
10
100
100
80
100
60
100
40
50
1
1
1
1
1
1
1
1
1
1
1
TTS 10Pro
Speed (mm/min)
3000
3000
6000
500
3000
3000
1500
3000
3000
3000
3000
TTS 10Pro
Power (%)
40
40
10
100
100
40
100
60
100
40
50
For Cutting ：
EN
Note:
The energy value is set to 500, and the laser intensity accounts for 50% of the power.
The energy value is set to 1000, and the proportion of laser intensity to power is 100%. The larger the energy, the
faster the speed can be set.
The above parameters only for reference. Due to the different properties of the materials, please adjust the parameter
values according to the actual situations.
Material
TTS 5.5Pro
Speed (mm/min)
TTS 10Pro
Times
Plywood 1mm
Plywood 2mm
Plywood 3mm
Plywood 4mm
Plywood 5mm
Plywood 6mm
Plywood 7-8mm
Acrylic 1mm
Acrylic 3mm
Acrylic 6mm
200
100
100
100
100
100
100
100
100
100
TTS 10Pro
Speed (mm/min)
Power (%)
100
150
150
150
150
150
150
150
150
150
100
100
100
100
100
100
100
100
100
100
1
1
1-2
1-2
3
2-3
2—3
1
1-2
2-3
TTS 5.5Pro
Times
1
1
2-3
2-3
2-3
3-4
3—4
1
2-3
3-5
Sculpt objects
"Engraving" uses the 1 step
"Cutting 2mm" uses the 2 step
"Cutting 4mm" uses the 3 step
"Cutting 6mm" uses the 4 step
TTS-55 PRO
5.5W Blow air block fixed
focus introduction
Focus adjustment before engraving:
Before engraving, the focus need to be adjusted. The focus needs to be on the surface of the engraved object. It can
use a fixed-focus column for auxiliary adjustment. Place the fixed-focus column between the engraved object and the
adjustment block, and rotate the Z-axis lifting module to make the laser module stick on the 1st steps of the fixed
focus column.
Focus adjustment before cutting: (Be careful of damage to the laser hood by impact)
Before cutting, the focus needs to be in the middle of the fault of the engraved object, so according to different plate
thicknesses, the corresponding focus should be set, and the Z-axis lifting module should be rotated to adjust.
Assuming the object is 2mm, use the 2nd step of the fixed focus column;
The object is 4mm, using the 3rd step of the fixed focus column;
The object is 6mm, using the 4th step of the fixed focus column.
Object
Laser module
Blow air block
Shading block
Fixed-length column
Fixed-length column
Engraving
uses the 1 step
Laser
module
TWO TREES
Cutting
The thickness of the engraved object
is 2mm Adopt the second step
Laser
module
Sculpt objects
2.00
TWO TREES
ADJUST THE FOCUS
