TYAN S5630 - Page 20

http://www.tyan.com
20
ID LED_BTN1: Rear IDLED Button
Signal
Pin
Pin
Signal
IDLED_SW#
1
2
GND
IPMB_HD1: IPMB Connector
Signal
Pin
Pin
Signal
BMC_SMB_DATA
1
2
GND
BMC_SMB_CLK
3
4
VCC
COM2: COM2 Header
Signal
Pin
Pin
Signal
DCD
1
2
DSR
RXD
3
4
RTS
TXD
5
6
CTS
DTR
7
8
RI
GND
9
10
KEY
J29: System FAN Connector
Signal
Pin
Pin
Signal
TACH1
1
2
TACH6
TACH2
3
4
TACH7
TACH3
5
6
TACH8
TACH4
7
8
TACH9
TACH5
9
10
TACH10
GND
11
12
KEY
PWM2
13
14
PWM1
TACH11
15
16
SMB_DATA
TACH12
17
18
SMB_CLK
NC
19
20
PWM3
INTRUDER_HD1: Chassis Intrusion Header
Signal
Pin
Pin
Signal
PCH_INTRUDER_N
1
2
GND
